Are you concerned about the safety of your home and the well-being of your loved ones when you are away? Do you own an office or a business and worry that theft, robbery or other accidents might occur during your leisure time?


Well, it is time to meet AX PRO – the advanced alarm system that helps guarantee the safety of your valuables, with continuous protection and real assurance 24 hours a day. Featuring precise detection and instant visual alarm verification, the AX PRO is the first wireless intrusion alarm system for homes and businesses that integrate comprehensive intrusion detection with smart automation, video security, video intercom, access control, and more.

Why choose AX PRO

Wireless and hassle-free, the AX PRO system is the perfect combination of efficiency, reliability and innovation that guarantees accurate detection without wires and without problems.

Visible alarms for real assurance

With AX PRO, home- or business-owners can verify alarms by watching video clips or GIF imaging when they are away from their property, staying informed in real time and resting easy with real assurance.

Multi-dimensional detection for comprehensive protection


Along with instant visual verification for all-around intrusion protection, the AX PRO helps keep an eye on every corner of your place, indoors and out, including early warning of smoke and fire, water or gas leaks, and more. The sleek, modern design suits virtually any home or office environment.

Software features

  • Tag: 32
  • Area: 16
  • Zones: 64 (up to 48 PIRCAMs)
  • Installer: 1
  • User: 30
  • Admin: 1
  • Voice Prompt: Supported
  • Loudspeaker built in: Supported
  • Memory Log stored: 5000
  • Programming tools: Hik-Connect/Hik-ProConnect/Web Portal/ IVMS4200/ Convergence Cloud
  • Firmware upgrade: APP/Web Portal
  • Arm modes: Away/Stay
  • Automatic Arm/Disarm Timers: Supported
  • Forced Arming with Open Zones: Supported
  • Diagnostics via the APP or Web: Supported
  • ARC protocol:

    SIA DC09(SIA level 2, Contact ID), ISUP, ISAPI (SDK)

    Hik-IP Receiver & Hik-IP Receiver Pro (Sur-Gard & Ademco 685)

    Supports video verification and remote control

  • User APP for operating: Supported
  • Installer APP for programming: Supported
  • Web server for maintenance (offline configuration): Supported

Hardware features

  • RS232 output: Supported
  • SIM slot: Single

RF transmission

  • RF Frequency: 868Mhz
  • Wireless Security: Frequency Hoping 128 AES Encryption
  • GPRS on board: Supported

Electrical characteristics

  • Power supply: Built in power supply
  • Battery type: Built in on board Battery Li
  • Battery life span: Up to 16 hours

Wireless transmission

  • Wired network: Supported
  • Wi-Fi Standard: Supported


  • LEDs Status: Arm/Disarm, Alarm, Tamper, Fault, Cloud, Power


  • Operation temperature: -10 °C to +55 °C
  • Shell material: Plastic
  • Dimension(WxHxD): 170.0 mm (6.7") x 170.0 (6.7") mm x 38.6 mm (1.5")
  • 557.5 g(19.7 oz)
  • Color: White

Device management

  • Keyfob: 32
  • Wireless sounder: 4 (2 internal+2 External)
  • Keypad: 8 (Including Tag reader)
  • Wireless Repeater: 2
  • Multi Transmitter: 4
  • PIR Cam: Supported
Weight .558 kg
Dimensions 20 × 19 × 40 cm
