Technical Spec'




Image display
Panel manufacturerHisense
Panel modelLCM: JHD425X1F52-T0K2, Open Cell :T430HVN01.2
Active display area, horizontal dimension (mm)940.896
Active display area, vertical dimension (mm)529.254
Screen size (rounded to nearest integer) (cm)108
Screen size (rounded to nearest integer) (inch)43
Display technologyLCD/ LED lit
Backlight sourceDirect LED
Resolution (Horiz x Vert) (pixel)1920*1080
Screen curvature radius (mm)-
Colour depth (bit)8bit
Image refresh frequency (Hz)60
Smooth motion rate60
3D image-
Typical brightness of white (cd/m2)250
Native contrast ratio3000 : 1
Viewing Angle (Horiz / Vert) (Degrees)178/  178
Quantum dotNo
Wide colour gamutNo
KSF phosphorNo
UHD PremiumNo
Response Time (ms)8
Connectivity
RF- Radio frequency input1
AV input1
AV output0
USB interface type 3.0 (Qty / List….)0
USB interface type 2.0 (Qty / List ….)2/ USB1, USB2
Optical digital audio output (SPDIF)1
Earphone jack1
HDMI ports
HDMI inputs2
HDMI type 8K@60HzNo
HDMI type 4K@60Hz with HDCP version 2.2No
HDMI 2.1  compliant inputNo
Enhanced Audio Return Channel ( eARC)No
CEC- Consumer Electronics Control via HDMIYes
Smart TV
Ethernet port (RJ45 connector)1
Wi-Fi  protocols IEEE 802.11 {b, g, n, ac, ad, ..}b, g, n
Wi-Fi bands (GHz)2.4
DLNA complianceYes
Bluetooth / BT versionNo / No
Anyview (Screen mirroring)Yes
Catch-up TV servicesIview,  SBS on Demand,  7 Plus, 9 Jumpin
(Tenplay available from Playsore)
UHD (4k) streamingNo
Installed Applications {List ……}Netflix/Youtube/Prime Video/Foxtel/Stan/ABC iview/Kayo/Tubi/SBS ON DEMAND/Facebook Watch/NBA
Freeview Plus - HbbTV 2.0Yes
Web browser [Chrome | Opera | Other]Odin
Digital TV reception
Television system (DVB-T / DVB-T2)Yes / Yes
Video decoder (MPEG2 / MPEG 4)Yes / Yes
AC3 Surround sound decoderYes
AS 4599.1 complianceYes
AS 4933.1 complianceYes
LCN- Logical channel number and DTV Service name supportYes
Teletext  / Teletext signal interruption (TAB compliant) / 16 : 9 TLTXYes / Yes / Yes
SubtitlesYes
RF Signal strength indicatorYes
RF Signal quality indicatorYes
RF Bit error rate indicatorYes
EPG- Electronic programming guide, 7 days for all servicesYes
Audio description (vision impairment aid)Yes
Parental rating lockYes
Analogue TV reception
Colour-Sound systems in VHF bandPALSECAM, B/G, D/K, I
Colour-Sound systems in UHF bandPALSECAM, B/G, D/K, I
Stereo sound decoder {A2, Nicam, ….}No
Teletext  / Teletext signal interruption (TAB compliant) / 16 : 9  TLTXNo/ No/ No
SubtitlesYes
Image processing
Backlight controlNo
Light sensingNo
Dynamic backlight controlNo
Frame rate controlNo
Variable Refresh Rate (VRR)No
FreeSyncNo
Auto Low Latency Mode for VRRNo
Local dimming/ controllable zonesNo
Zoom function settingsAutomatic/ 16:9/ 4:3/ Panoramic/
Movie Zoom/ Direct
1:1 Pixel mappingNo
HDR - High Dynamic Range for luminance (DMP / Netflix / HDMI)No / No / No
HDR system (HDR10 / HDR10+ / Dolby Vision)No / No / No
HLG (Hybrid Log-Gamma) for HDRNo
HEVC (H.265) decoderNo
Dual image (PIP / POP)No/ No
Motion enhancement and compensation (MEMC)No
Input lagNo
Sound
Audio power output per channel (Watt)7
Number of speakers (Tweeter / Midrange / Woofer)2 /0 /0
Automatic volume level (AVL)Yes
Audio equalizerYes
Dolby DigitalYes
Audio enhancement -Type {SRS, BBE, SAP, DBX-TV….}DTS Virtual X
Lip-sync  adjustmentYes
Features
On/off timerYes
Power off if no signalYes
Sleep timerYes
Program lockYes
OSD transparency controlYes
User interfaceVIDAA U5
Software version OSD indicationYes
Legal requirements: Disclaimer / Acceptance of TermsYes / Yes
Favourite channels listYes
Electronic point of sales (E-POS)Yes
OTA- Over the air software updatesYes
Voice commandNo
Screen mirroring {Miracast, Anyview Cast, ...}Anyview Cast
Smartphone remote control application {Rremote Now, ...}Yes
Replaceable demo video for Store modeYes
Remote control via serial portNo
USB media player
Personal Video RecorderYes
Time ShiftYes
DTV Recording (EPG scheduling / start from Standby )Yes / Yes
DivX decoderNo
MPEG4 (H.264) / H.265 decoderYes / Yes
DMP- Digital media player content (Music / Video / Photos / Text)Yes / Yes / Yes / No
DMP Auto-playNo
DMP for UHD content via USBYes
DMP File allocation table (FAT / FAT32 / exFAT / NTFS)Yes / Yes  / No / Yes
PVR  File allocation table (FAT / FAT32 / exFAT / NTFS)Yes / Yes / No / Yes
Hotel lock
Protected Hotel lock submenu (Password / fixed code)No / Yes
Clone function for programs, sound and image settings.Yes
Sub-menu lock, including tuning lockYes
Keyboard lockYes
Maximum volume lockYes
Power on volumeYes
Power on, apply default sound/image settingsNo
Power on source selectionYes
Power on RF channel selectionYes
Power on mode (On / Standby / Last)Yes / Yes / Yes
Inputs access (Enable / Disable)Yes
Hardware
Processor / CoresMT9602GAATBB / 4
Dual TunerNo
Colour (Front bezel, rear, stand)Black / Black /  Black
Speakers mounted in enclosureYes
Mains  power switchNo
Swivel baseNo
Compact packagingYes
Supply  range [Voltage / Frequency] (Volt / Hz)100 ~ 240V / 50Hz
Standby consumption (Watt)< 0.5W
Maximum time delay Power On to sound an image (sec)30
Installation
Stand area (Width / Depth) (mm)806×186
Wall mount dimensions (Horiz x Vert) (mm)200X200
Wall mount, screw thread (mm)M6/ 10mm
VESA complianceYes
Detachable power cordNo
Power cord length (cm)155
Accessories
Remote controller (Technology / Part number )IR /EN2B36H
Battery (size / quantity)AAA / 2
User manual (Available online) / Quick setup guide (Print)1 / 1
Warranty [In User manual | In separate sheet]In separate sheet
Skype camera (Qty / Part number)-
3D glasses type  [Passive | Shutter] / Link [RF | IR | BT]-
3D glasses (Qty / Part number)-
Dimensions
Dimensions with stand (W/H/D) (mm)955×606×186
Dimensions without stand (W/H/D) (mm)955×558×87
Carton box dimensions (W/H/D) (mm)1070×135×652
Net weight (with stand / without stand) (kg)6.5  kg /6.4  kg
Gross weight (kg)9.2 kg
Container load (20ft / 40ft / 40ft HC)273/567/756
Licensing and certification
EMC- Electromagnetic CompatibilityYes
CB- Electrical safetyYes
HDMIYes (Hisense internal test)
Dolby DigitalYes
MEPS- Test reportYes
ROHSNo
Electrical safety  conformity for AustraliaYes
Documentation
Panel specificationsYes
Initial specifications (input form)Yes
Confirmed product specificationsYes
List of DMP formats for audio and videoYes (QSG)
(Required before purchase order)
Documentation
CB report and certificateYes
EMC report and certificateYes
Power cord, plug and connector Australian safety approvalYes
Weight 9.2 kg
Dimensions 107 × 13.5 × 65.2 cm
