Technical Spec'




Hardware
Processor / CoresMSD6886NQHAT-8-00GG/ 4
Dual TunerNo
Colour (Front bezel, rear, stand)Black / Black / Black
Speakers mounted in enclosureYes
Mains power switchNo
Swivel baseNo
Compact packagingYes
Maximum time delay Power On to sound an imagesec
Hotel Lock
Protected Hotel lock submenuFixed code
Clone function for programs, sound and image settingsYes
Sub-menu lock, including tuning lockYes
Keyboard lockYes
Maximum volume lockYes
Power on volumeYes
Power on, apply default sound/image settingsYes
Power on source selectionYes
Power on RF channel selectionYes
Power on mode (On / Standby / Last)Yes / Yes / Yes
Inputs access (Enable / Disable)Yes
USB Media Player
Personal Video RecorderYes
Time ShiftYes
DTV RecordingEPG scheduling, Start from Standby
DivX decoderNo
MPEG4 H.264 / H.265 DecoderYes / Yes
DMP – Digital media player contentMusic, Photos, Video
DMP Auto-playYes
DMP for UHD content via USBYes
DMP File allocation tableFAT, FAT32, NTFS
PVR File allocation tableFAT, FAT32, NTFS
Image processing
Backlight controlYes
Light sensingNo
Dynamic backlight controlYes
Local dimming / controllable zonesNo
Zoom function settings16:9, 4:3, Auto, Zoom 1, Zoom 2
1:1 Pixel mappingYes
HDR – High Dynamic Range for luminanceDMP, HDMI, Netflix
HDR systemDolby Vision, HDR10
HLGYes
HEVC (H.265) decoderYes
Dual imageNo
MEMCYes
Analogue TV Reception
Colour-Sound systems in VHF bandPAL B
Colour-Sound systems in UHF bandPAL B
Stereo sound decoder (Analogue)A2, NICAM
Teletext / Teletext signal interruption (TAB compliant) / 16 : 9 TLTX (Analogue)Yes / Yes / Yes
Subtitles (Analogue)Yes
Digital TV Reception
Television systemDVB-T, DVB-T2
Video decoder (MPEG2 / MPEG 4)MPEG2, MPEG4
AC3 Surround sound decoderYes
AS 4599.1 ComplianceYes
AS 4933.1 ComplianceYes
LCN – Logical channel number & DTV Service name supportYes
Teletext / Teletext signal interruption (TAB compliant) / 16 : 9 TLTXYes / Yes / Yes
SubtitlesYes
RF Signal strength indicatorYes
RF Signal quality indicatorYes
RF Bit error rate indicatorYes
EPG - Electronic Programming Guide, 7 days for all servicesYes
Audio description (vision impairment aid)Yes
Parental rating lockYes
Smart TV
Ethernet RJ45 port1
Wi-Fi protocols IEEE 802.11 [b, g, n, ac, ad, ..]a, ac, b, g, n
Wi-Fi bands2,4 GHz
Network Streaming (DLNA)Yes
BluetoothYes
Bluetooth Version5
Anyview CastYes
UHD (4k) streamingYes
Installed AppsAccuWeather, Anyview Cast, BOLT+, DEOD, DStv Now, E-manual, Filmbox, FITE, Game Center, Kidoodle TV, Media, mindset, Netflix, Plex, Prime Video (Amazon), Redbull TV, SHOWMAX, Toon Goggles, TV Browser, VIDAA Art, VIDAA Free, Viu, YouTube, YouTube Kids, YuppTV
Freeview Plus – HbbTV 2.0Yes
Web browserOdin 2.10
Eco & Power Supply
Power Consumption (Stand-by)< 0.5 W
Voltage100 – 240V
Frequency50 – 60Hz
Functions
Smartphone appYes
Safety and Regulation
CBYes
EMCYes
HDMINo
RoHSNo
Accessories
Remote BatteriesAAA x 2
User ManualYes
Quick Start PageYes
Stand area1445 × 375mm
Wall mount dimensions400 x 300 mm
Wall mount, screw threadM6
VESA complianceYes
Detachable power cordYes
Power cord length155 cm
Remote controller (Technology / Part number)IR / EN2P30H
WarrantyIn separate sheet
Weight & Dimensions
Carton box dimensions (W x H x D)1765 × 211 × 1075mm
Gross Weight (Kg)30kg
Dimensions with stand (W x H x D)1577 × 953 × 375mm
Dimensions without stand (W x H x D)1577 × 883 × 84mm
Net weight (with stand / without stand)21.5 / 21kg
Connectivity
HDMI inputs3
HDMI1ARC, HDMI 2.0, HDMI type 4K@60Hz with HDCP version 2.2
HDMI2HDMI 2.0, HDMI type 4K@60Hz with HDCP version 2.2
HDMI3HDMI 2.0, HDMI type 4K@60Hz with HDCP version 2.2
Radio frequency input1
AV Input1
USB (2.0)2
S/PDIF Output1
Earphone jack1
Ethernet RJ45 port1
Features
On / Off timerYes
Power off if no signalYes
Sleep timerYes
Program lockYes
OSD transparency controlYes
User Interface (UI)VIDAA U4
Software version OSD indicationYes
Legal requirementsAcceptance of Terms, Disclaimer
Favourite channel listYes
Electronic point of sales (E-POS)Yes
OTA - Over the air software updatesYes
Voice commandNo
Screen mirroringAnyview Cast
Smartphone appYes
Replaceable demo video for Store modeYes
Remote control via serial portNo
Internet
Installed AppsAccuWeather, Anyview Cast, BOLT+, DEOD, DStv Now, E-manual, Filmbox, FITE, Game Center, Kidoodle TV, Media, mindset, Netflix, Plex, Prime Video (Amazon), Redbull TV, SHOWMAX, Toon Goggles, TV Browser, VIDAA Art, VIDAA Free, Viu, YouTube, YouTube Kids, YuppTV
Web browserOdin 2.10
Anyview CastYes
Sound
Audio Power Output (p/ch)15W
Number of speakers (Tweeter / Midrange / Woofer)1 / 1 / 0
Automatic volume level (AVL)Yes
Audio equalizerYes
Audio enhancement – Type [SRS, BBE, SAP, DBX-TV...]DTS Studio sound
Lip-sync adjustmentYes
Dolby DigitalYes
Technical Details
Resolution (DPI)3840 x 2160
HDMI-CEC SupportYes
MHL SupportNo
Network Streaming (DLNA)Yes
Wide Colour GamutNo
MEMCYes
HLGYes
Basic Information
Resolution (DPI)3840 x 2160
Display TechnologyLCD / LED lit
RoHSNo
User Interface (UI)VIDAA U4
Active display area dimension1549.44 x 846.72mm
Screen size (rounded to nearest integer)177cm, 70 "
Backlight sourceLED Matrix
Display Colour depth8bit+FRC
Image refresh frequency60Hz
Smooth motion rate120
Maximum brightness of white360 cd/m2
Native contrast ratio5000 : 1
Viewing Angle (Horiz / Vert)178 / 178 Degrees
Quantum dotNo
Wide Colour GamutNo
UHD PremiumNo
Response Time8 ms
Weight 30 kg
Dimensions 176.5 × 21.1 × 107.5 cm
