Technical Spec'


Factory Model No.55E80GEVS
Model No.55U8H
Front-cover Material/ColorPlastic/Dark Grey
Back-cover Material/ColorPlastic/Black
Frame Design/MaterialOne body/Stainless steel
TV TypeMini-LED ULED 4K Smart TV
Panel Performance
Panel TypeADS
Anti-reflectant screenNo
Panel Aspect Ratio16:9
Panel Response Time (ms)8
Screen Size (diagonal)54.6inch
Screen Size (diagonal) CM138.8
Visible Screen Area (cm^2)8230.1
Max. ResolutionUltra HD 3840×2160
Curvature Rate-
Angle of visibility178°
Display Color Depth8bit+FRC
TCON color depth8bit+FRC
Wide Color GamutYes
Quantum Dot TechNologyYes
Color gamut range (DCI-PC3)> 95%
Vsync Frequency120Hz
TV Brightness (nits)(Typical Value)500
TV Peak Brightness (nits) and Duration (s)1300
Backlight techNologyDLED
Local DimmingYes
Local Dimming Zones112
Black Level (nit)0.15
3D techNologyNo
2D to 3DNo
PCI( Picuture Criteria Index)2800
Dolby VisionYes
Improving Engines
ProcessorQuad Core/MT9900
Upscaling Ultra HDYes
DecoderHEVC (H.265),VP9,H.264,MPEG4, MPEG2,AV1
Game Mode LevelGame Mode Pro
Game Mode(Input Lag)Yes (<20ms)
3D Digital Comb FilterYes
MPEG Noise reductionYes
Mosquito Noise reductionYes
UHD PremiumYes
IMAX EnhancedYes
Filmmaker modeYes
Dolby Vision IQYes
HDR10+ AdaptiveYes
Freesync PremiumYes
Sound output power4*10W+20W+2*5W
Sound TechNologyDolby Atmos, DTS Virtual X
NICAM / A2 StereoNICAM Stereo
User EqualizerYes
Sound - SpecialDolby Audio(MS12), DTS
Media PlayerYes (Video, Audio, Picture)
Multi-Language OSD参考sheet Area List + PVR
Hotel TVYes
User InterfaceVIDAA U6.0
Important Apps (all countries)refer to APP sheet
Country-specific appsrefer to APP sheet
Web browserOdin
HbbTVHbbTV 2.0.3
MHEG supportYes (but only if Certification requires,e.g. Ziggo)
Anyview CastYes
Anyview StreamYes (DMP,DMR)
Smartphone appYes
Airplay2 SupportTBD
Voice Service SupportVIDAA Voice
Mid-field Voice SupportYes
Reception and TV Features
Digital and Analog TunerDVB-T2/T/C/S2/S
LCN SupportYes (Depending on location and operator)
Teletext SupportYes
EPG8 days forward EPG,
7 days backwards EPG (UK Only)
Parental ControlYes
PVR参考 , ref
Area List + PVR
Time Shift参考 , ref
Area List + PVR
Channel sortingBuild-in and exportable for PC edit (ChSort)
Favorite channel list4
Common Interface (CI+)Yes  (CI+ ECP)
HDMI3HDMI2.1 (eARC, ALLM, VRR (120Hz))
HDMI4HDMI2.1 (ALLM, VRR (120Hz))
USB (2.0)1
USB (3.0)1
S/PDIF Output1
Audio (L/R) Input1(mini)
Headphone Output1
RF Tuner2
Composite (AV) Input1(mini)
Component YPb(Cb)/Pr(Cr) Input0
VGA Input0
PC Audio Input (3.5mm)0
Ethernet RJ45 portYes(100M)
Wireless LAN adapter SupportYes
WiFi techNolegyIEEE 802.11 a/b/g/n/ac/ax (2.4G 5G and 6G)
Bluetooth Support and profilesYes (BT5.0)
light sensorYes
Eco & Power supply
Power Supply VoltageAC100~240V
Energy Efficiency Class (SDR)G
Energy Efficiency Class (HDR)G
Network Standby Consumption≤2W
Standby Consumption≤0.5W
Power off ConsumptionNA
Power Consumption (Nameplate)230W
Annual Consumption (Nameplate)NA
Power Consumption SDR (Energy Rating Label)82W
Power Consumption HDR (Energy Rating Label)170W
1000h Consumption SDR (Energy Rating Label)82kWh/1000h
1000h Consumption HDR (Energy Rating Label)170kWh/1000h
Luminance Ratio>230nit
Mercury contentYes -This television contains mercury only in certain parts or components, in accordance with existing exemption clauses under the RoHS Directive.
Lead contentYes -This television contains mercury only in certain parts or components, in accordance with existing exemption clauses under the RoHS Directive.
Weight & Dimensions
Weight incl. Packaging32.0kg
Product weight incl. Stand24.5kg
Product weight excl. Stand19.4kg
Weight of carton box6.0kg
Weight of plastic foam in package material1.4kg
Weight of plastic in package material0.1kg
Weight of metal in package material0
Package (Horizontal/Vertical)Vertical
Packaging Dimension (LxDxH)1451×194×874 mm
Product Dimension incl. Stand (LxDxH)1233×300×784 mm
Product Dimension excl. Stand (LxDxH)1233×77×734 mm
Maximum distance between two stand(L)底座间最大尺寸NA
Bezel width(Top/Left&right/Bottom)0/0/38mm
Single standYes
Adjustable StandNo
Minimum distance between the standsNA
Cable ManagementYes
Stand Material / ColorMetal/Dark Gray
Stand (LxW)400×300mm
VESA Wall Mount Compatible400×300mm
Second Remote Control (Model number)No
Remote BatteriesAA×2(Mid-field voice remote)/AAAx2(None mid-fileld voice remote)
User ManualYes
Quick start pageYes
Power cableYes
Weight of packaging
Weight of packaging -paper, cardboard6.0kg
Weight of packaging- EPS1.3kg
Weight of packaging- foil PE0.02kg
Weight of packaging- PVC0
Weight of packaging- plastic- other0.1kg
Weight of packaging- wood0
Weight of packaging- metal0
Weight of packaging -paper0
Logistics & Warranty
堆码层数Number of packaging units3
整机装箱量Container Loading(40HQC)  294
DMP formats
Container FormatAVI,MP4,MKV,TS,FLV OGG
music(mp3 aac wma wav)
Weight 32 kg
Dimensions 145.1 × 19.4 × 87.4 cm
